Cash or Certified Check Price: $7,965.00
|
For sale in Poughkeepsie, NY
CAM 20235-TON 6' x 12' TANDEM AXLE TILT TRAILER
5CAM612FTT http://camsuperline.com/pdfs/2017_TTTA.pdf
NOTE: OUR INVENTORY CHANGES OFTEN. WE DO OUR BEST TO KEEP OUR STOCK INFORMATION UP-TO-DATE. PLEASE CONTACT US FOR MORE INFO. THANK YOU.
5CAM612FTT
GVWR: 11,000 lbs.
EMPTY WEIGHT: 2,300 lbs.
PAYLOAD: 9,660 lbs.
DECK LENGTH: 12'
OVERALL WIDTH: 96"
USEABLE DECK WIDTH: 75" (81")
DECK HEIGHT: 16"
AXLE CAPACITY: 5,080 lbs.
RADIAL TIRE SIZE: 225/75R15LRD Silver Wheels
SPARE TIRE MOUNT
MAINFRAME: 6" x 4" x 5/16" Angle
CROSSMEMBERS: 3" Channel @ 4.1#
TONGUE: 5" Channel @ 6.7#
Dexter E-Z Lube(tm) Axles (4" Drop)
Nev-R-Adjust Brakes
Slipper Spring Suspension
Electric Brakes
Adjustable Hydraulic Cushion Cylinder
Diamond Plate Fenders
Spare Tire Mount
7K Jack
LED Lights - Rubber Mounted
Adjustable 2-5/16" Ball Coupler or Pintle
D-Ring Tie Downs - 5/8"
(4)
(2) Banjo Eye Tie Downs
Pressure Treated Pine Decking
Silver Wheels
Zip Breakaway System
Sealed Wiring Harness
7-Way SAE Plug
Safety Chains
Epoxy Primer
Polyurethane Paint Finish
Colors (standard): Black, Yellow
Three Year Warranty
The 6x12 tilt deck is mounted with a pivot point strategicaly located which allows it to tilt into the loading position via gravity. A tongue mounted hydraulic cushion cylinder provides variable adjustability of the gravity powered tilt operation. A hydraulic flow control valve with adjustment knob allows the user to control the speed at which the deck is tilted. A locking heavy duty latch secures the deck for transportation.
Standard decking is inch and a half tight-grained northern hemlock which provides long lasting durability and enhanced resistance to weathering. When hauling smaller equipment with a narrow concentrated center of weight, CAM Superline strongly recommends a forklift tread package. This tread...
Stock #: FPCAM533675
